Ubiquiti U6-Enterprise-IW UniFi In-Wall Tri-Band WiFi 6E Access Point (10.2Gbps AX)

Ubiquiti UniFi U6 Enterprise In-Wall WiFi 6 Tri-Band Access Point
Ubiquiti UniFi U6-Enterprise offers cutting-edge, tri-band WiFi 6 coverage in your home or business. Offering up to 10.2 Gbps aggregate throughput and support for 2.4Ghz, 5Ghz and 6Ghz bands - this is a truly flexible, future-proof access point for high traffic environments.

Featuring a 2.5Gb Ethernet LAN connection, for the ultimate in high-speed connection and transfer rates. The U6-Enterprise-IW can also be powered by PoE+ giving users convenience and ease-of-use.

The UniFi U6-Enterprise-IW is housed in a sleek, minimalist white plastic enclosure for low profile installs in-wall.

Key Features
WiFi 6 support (2.4/5/6 GHz bands)
10.2 Gbps aggregate throughput rate
1 x 2.5GbE RJ45 port (PoE In)
Powered with PoE+

Specifications

Mechanical

Weight & Dimensions
159.7 mm x 156.7 mm x 33.8 mm
Weight884g

Enclosure material
Polycarbonate, aluminum

Mount material
Aluminum

Hardware

Networking interface
(1) Data in: 2.5 GbE RJ45 port
(4) Data out: GbE RJ45 ports

Management interface
Ethernet
Bluetooth

PoE interface
(1) PoE+ input
(1) PoE output

Power method
PoE+
PoE++ (Required for PoE output)

Power supply
UniFi PoE switch

Max. power consumption
21W (Excluding PoE output)

Max. PoE wattage per port by PSE
15.4W

Supported voltage range
44—57V DC

Max. TX power
2.4 GHz - 22 dBm
5 GHz - 26 dBm
6 GHz - 26 dBm

MIMO
2.4 GHz - 2 x 2 (UL MU-MIMO)
5 GHz - 4 x 4 (DL/UL MU-MIMO)
6 GHz - 4 x 4 (DL/UL MU-MIMO)

Throughput rate
2.4 GHz - 573.5 Mbps
5 GHz - 4.8 Gbps
6 GHz - 4.8 Gbps

Antenna gain
2.4 GHz - 4 dBi
5 GHz - 5.8 dBi
6 GHz - 5.8 dBi

LED
White/blue

Button
Factory reset

Mounting
Wall (Included)

Operating temperature
-30 to 60° C (-22 to 140° F)

Operating humidity
5 to 95% noncondensing

Certifications
CE, FCC, IC

Software

WiFi standards
802.11a/b/g/n/ac/ax (WiFi 6/6E)

Wireless security protocols
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)

BSSID
8 per radio

VLAN
802.1Q

Advanced QoS
Per-user rate limiting

Guest traffic isolation
Supported

Concurrent clients
600+

Zero-wait DFS
Yes

Supported Data Rates

802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b
1, 2, 5.5, 11 Mbps

802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (WiFi 4)
6.5 Mbps to 600 Mbps (MCS0 - MCS31 , HT 20/40)

802.11ac (WiFi 5)
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (WiFi 6/6E)
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

Application Requirements

UniFi Network
Version 7.2.85 and later

Box Contents
1 x U6-Enterprise-IW access point
1 x In-wall mounting plate
4 x Mounting screws
1 x Allen key
