Full metal mesh design on the top and right side panel
Side panels could be removed without top panel removed first
Ample width to perfectly support wider 40-series graphics cards
Mesh at the bottom provides great air intake
Stylish power supply bracket design
Pre-installed with four velcro straps for easy cable routing
Bottom: 2 x 160 x 35mm Tranquil Reverse ARGB PWM fans
Rear: 1 x 140 x 25mm Tranquil ARGB PWM fan
Built-in ARGB & PWM Fan Control Hub in sync with M/B
Vertical Cooling
Can accommodate three 140mm or two 160mm fans each on top and bottom for efficient GPU cooling.
Dual Chamber
Independent cooling for CPU/GPU on the left side & PSU/Drives on the right side.
Best Cooling Design
Support 360mm radiators on top, bottom and side simultaneously for liquid cooling.
Up to 10 fans simultaneously.
Supports 2 x 160mm fans on top / 2 x 160mm fans on bottom / 1 x 140mm at rear.
Bottom Fan Configuration
Comes with interchangeable fan brackets to cater to fans of different sizes.
Air Intake and Dust Filter
Top: Full mesh panel.
Right side: Full mesh panel.
Bottom: Full-sized pull-out dust filter.
0.8mm + 1.0mm thick steel & Tool-Free design
The ultra robust 0.8mm & 1mm steel brings unwavering protection, and the tool-free quick-release panels on the front, top and sides make the assembly and cleaning of components simplified than ever.
Graphics Cards Installation
Provides ample width to perfectly support wider RTX40 series GPU.
Supports vertical GPU riser cable after removal.
Features 8 reusable PCIe slot covers.
Vertical Graphics Card Installation.
Power Supply Installation
Stylish PSU bracket with rubber pad to prevent scratch
Vast room to house power supplies up to 210mm in length
Support side-interface power supplies
I/O Panel
Mainstream Type-C (10Gbps) port for high-speed transmission.
Dust plugs for dust prevention.
Mic/Audio 2-in-1 port.
Modular Drive Trays
Supports up to 6 drives: 2*3.5" HDD & 4*2.5" SSD
0-761345-10022-9
Data sheet
.
Radiator Support:Top: Up to 360 mmSide: Up to 360 mmBottom: Up to 360 mmRear: 120 mm
Warranty
2 Years
Form Factor
E-ATX
Additional Features
See Overview
Colour
Black
Weight/Dimensions
11.84 kg(DxWxH) 464 x 303 x 476 mm
Material
Steel + PlasticFront and Right Side: Tempered Glass
Power Supply Wattage
No PSU
Motherboard Support
E-ATX (280mm), ATX, Micro ATX, Mini ITX
Connectors / Controls
1 x USB Type-C 10Gbps2 x USB 3.0Headphone/Mic Combo JackPower ButtonReset Button
Drive Bays
2/0 x 3.5" /2.5" 4 x 2.5"
Compatibility
GPU max length:440 mm CPU cooler max height:175 mm PSU max length:210 mm (without cable)
LED Lighting
Yes (LED Lighting)
Small Form Factor
No
Expansion Slots
8 Expansion Slots
Window(s)
Yes (Window)
