Gigabyte GeForce RTX 2060 SUPER GAMING OC WHITE 8GB Triple Fan Graphics Card

Powered by GeForce RTX 2060 SUPER
Integrated with 8GB GDDR6 256-bit memory interface
WINDFORCE 3X Cooling System with alternate spinning fans
RGB Fusion 2.0 synchronize with other AORUS devices
Metal Back Plate

Core Clock
1815 MHz (Reference Card: 1650 MHz)

WINDFORCE 3X COOLING SYSTEM
The WINDFORCE 3X cooling system features 3x 80mm unique blade fans, alternate spinning fan, 4 composite copper heat pipes, heat-pipe direct touch and 3D active fan functionality, together delivering an effective heat dissipation capacity for higher performance at lower temperatures.

ALTERNATE SPINNING
The GIGABYTE patent Alternate Spinning is the only solution that can solve the turbulent airflow of three fans. The biggest problem with the three fans is turbulence. Since the fans rotate in the same direction, the airflow direction is opposite between the fans, which will cause turbulent airflow and reduce heat dissipation efficiency. GIGABYTE turns the middle fan in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.

UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the airflow.

3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.

HEAT PIPES DIRECT TOUCH
The shape of the pure copper heat pipe maximizes the direct contact area with the GPU, enhancing heat transfer. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.

COMPOSITE HEAT-PIPE
The composite heat-pipe combines thermal conductivity and phase transition to efficiently manage the heat transfer between two solid interfaces which increases cooling capacity.

RGB FUSION 2.0
With 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices.

EXTREME DURABILITY AND OVERCLOCKING
The graphics card uses the 8+2 power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.(Reference card is 5+2)

PROTECTION METAL BACK PLATE
The metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.

POWER INDICATORS
The smart power LED indicator alerts the player when any PCI-E power supply is abnormal.

Specifications

Graphics Processing
GeForce RTX 2060 SUPER

Core Clock
1815 MHz (Reference Card: 1650 MHz)

RTX-OPS
45

CUDA Cores
2176

Memory Clock
14000 MHz

Memory Size
8 GB

Memory Type
GDDR6

Memory Bus
256 bit

Memory Bandwidth (GB/sec)
448 GB/s

Card Bus
PCI-E 3.0 x 16

Digital Maximum Resolution
7680x4320@60Hz

Multi-View
4

Card Size
L=280.35 W=116.45 H=40.24 mm

PCB Form
ATX

DirectX
12

OpenGL
4.5

Recommended PSU
550W

Power Connectors
8 Pin*1, 6 Pin*1

Output
DisplayPort 1.4 *3
HDMI 2.0b *1
USB Type-C (support VirtualLink) *1

SLI Support
No

Accessories
1. Quick guide
2. Driver CD
